Amazon RDSのパラメータグループのパラメータの変更可否

Amazon RDSのパラメータグループの各パラメータは、AWS マネージメントコンソールにログインして確認可能ですが、本日時点(2018/12/13)での主なパラメータグループを貼り付けておきます。以下のAWS CLIとjq、columnコマンドを使って抽出しています。mysql 5.7, postgresql 9.5, oracle ee 12.1のdefaultのパラメータグループについて取得できたものを載せています。正確な値については、AWSマネージメントコンソールにログイン、あるいはAWS CLIAWS SDKを使って確認します。

aws rds describe-db-parameters --db-parameter-group-name default.mysql5.7 \
| jq -r '.Parameters[] | [.ParameterName, .IsModifiable, .ApplyMethod] \
| @tsv' | column -t

上記コマンドを実行して得られた結果は以下です。Parameter NameとIsModifiable, ApplyMethodのみ表示しています。

default.mysql5.7

IsModifiableが変更可能かどうか?、ApplyMethodが変更の適用タイミングです。

Parameter Name                                            IsModifiable ApplyMethod
allow-suspicious-udfs                                     false  pending-reboot
auto_generate_certs                                       false  pending-reboot
auto_increment_increment                                  true   pending-reboot
auto_increment_offset                                     true   pending-reboot
autocommit                                                true   pending-reboot
automatic_sp_privileges                                   true   pending-reboot
avoid_temporal_upgrade                                    true   pending-reboot
back_log                                                  true   pending-reboot
basedir                                                   false  pending-reboot
binlog_cache_size                                         true   pending-reboot
binlog_checksum                                           true   pending-reboot
binlog_error_action                                       true   pending-reboot
binlog_format                                             true   pending-reboot
binlog_group_commit_sync_delay                            true   pending-reboot
binlog_group_commit_sync_no_delay_count                   true   pending-reboot
binlog_gtid_simple_recovery                               true   pending-reboot
binlog_max_flush_queue_time                               true   pending-reboot
binlog_order_commits                                      true   pending-reboot
binlog_row_image                                          true   pending-reboot
binlog_rows_query_log_events                              true   pending-reboot
binlog_stmt_cache_size                                    true   pending-reboot
block_encryption_mode                                     true   pending-reboot
bulk_insert_buffer_size                                   true   pending-reboot
character-set-client-handshake                            true   pending-reboot
character_set_client                                      true   pending-reboot
character_set_connection                                  true   pending-reboot
character_set_database                                    true   pending-reboot
character_set_filesystem                                  true   pending-reboot
character_set_results                                     true   pending-reboot
character_set_server                                      true   pending-reboot
check_proxy_users                                         true   pending-reboot
collation_connection                                      true   pending-reboot
collation_server                                          true   pending-reboot
completion_type                                           true   pending-reboot
concurrent_insert                                         true   pending-reboot
connect_timeout                                           true   pending-reboot
core-file                                                 false  pending-reboot
datadir                                                   false  pending-reboot
default_authentication_plugin                             false  pending-reboot
default_password_lifetime                                 true   pending-reboot
default_storage_engine                                    false  pending-reboot
default_time_zone                                         false  pending-reboot
default_tmp_storage_engine                                false  pending-reboot
default_week_format                                       true   pending-reboot
delay_key_write                                           true   pending-reboot
delayed_insert_limit                                      true   pending-reboot
delayed_insert_timeout                                    true   pending-reboot
delayed_queue_size                                        true   pending-reboot
disabled_storage_engines                                  false  pending-reboot
disconnect_on_expired_password                            true   pending-reboot
div_precision_increment                                   true   pending-reboot
end_markers_in_json                                       true   pending-reboot
enforce_gtid_consistency                                  true   pending-reboot
eq_range_index_dive_limit                                 true   pending-reboot
event_scheduler                                           true   pending-reboot
explicit_defaults_for_timestamp                           true   pending-reboot
flush                                                     false  pending-reboot
flush_time                                                true   pending-reboot
ft_boolean_syntax                                         false  pending-reboot
ft_max_word_len                                           true   pending-reboot
ft_min_word_len                                           true   pending-reboot
ft_query_expansion_limit                                  true   pending-reboot
ft_stopword_file                                          true   pending-reboot
general_log                                               true   pending-reboot
general_log_file                                          false  pending-reboot
group_concat_max_len                                      true   pending-reboot
gtid-mode                                                 true   pending-reboot
gtid_executed_compression_period                          true   pending-reboot
gtid_purged                                               false  pending-reboot
host_cache_size                                           true   pending-reboot
init_connect                                              true   pending-reboot
innodb_adaptive_flushing                                  true   pending-reboot
innodb_adaptive_flushing_lwm                              true   pending-reboot
innodb_adaptive_hash_index                                true   pending-reboot
innodb_adaptive_hash_index_parts                          true   pending-reboot
innodb_adaptive_max_sleep_delay                           true   pending-reboot
innodb_autoextend_increment                               true   pending-reboot
innodb_autoinc_lock_mode                                  true   pending-reboot
innodb_buffer_pool_chunk_size                             true   pending-reboot
innodb_buffer_pool_dump_at_shutdown                       true   pending-reboot
innodb_buffer_pool_dump_now                               false  pending-reboot
innodb_buffer_pool_dump_pct                               true   pending-reboot
innodb_buffer_pool_filename                               false  pending-reboot
innodb_buffer_pool_instances                              true   pending-reboot
innodb_buffer_pool_load_abort                             false  pending-reboot
innodb_buffer_pool_load_at_startup                        true   pending-reboot
innodb_buffer_pool_load_now                               false  pending-reboot
innodb_buffer_pool_size                                   true   pending-reboot
innodb_change_buffer_max_size                             true   pending-reboot
innodb_change_buffering                                   true   pending-reboot
innodb_checksum_algorithm                                 true   pending-reboot
innodb_cmp_per_index_enabled                              true   pending-reboot
innodb_commit_concurrency                                 true   pending-reboot
innodb_compression_failure_threshold_pct                  true   pending-reboot
innodb_compression_level                                  true   pending-reboot
innodb_compression_pad_pct_max                            true   pending-reboot
innodb_concurrency_tickets                                true   pending-reboot
innodb_data_home_dir                                      false  pending-reboot
innodb_deadlock_detect                                    true   pending-reboot
innodb_default_row_format                                 true   pending-reboot
innodb_disable_sort_file_cache                            true   pending-reboot
innodb_fast_shutdown                                      true   pending-reboot
innodb_file_format                                        true   pending-reboot
innodb_file_per_table                                     true   pending-reboot
innodb_fill_factor                                        true   pending-reboot
innodb_flush_log_at_timeout                               false  pending-reboot
innodb_flush_log_at_trx_commit                            true   pending-reboot
innodb_flush_method                                       true   pending-reboot
innodb_flush_neighbors                                    true   pending-reboot
innodb_flush_sync                                         true   pending-reboot
innodb_flushing_avg_loops                                 false  pending-reboot
innodb_force_load_corrupted                               false  pending-reboot
innodb_ft_aux_table                                       true   pending-reboot
innodb_ft_cache_size                                      true   pending-reboot
innodb_ft_enable_diag_print                               true   pending-reboot
innodb_ft_enable_stopword                                 true   pending-reboot
innodb_ft_max_token_size                                  true   pending-reboot
innodb_ft_min_token_size                                  true   pending-reboot
innodb_ft_num_word_optimize                               true   pending-reboot
innodb_ft_result_cache_limit                              true   pending-reboot
innodb_ft_server_stopword_table                           true   pending-reboot
innodb_ft_sort_pll_degree                                 true   pending-reboot
innodb_ft_total_cache_size                                true   pending-reboot
innodb_ft_user_stopword_table                             true   pending-reboot
innodb_io_capacity                                        true   pending-reboot
innodb_io_capacity_max                                    true   pending-reboot
innodb_large_prefix                                       true   pending-reboot
innodb_lock_wait_timeout                                  true   pending-reboot
innodb_log_buffer_size                                    true   pending-reboot
innodb_log_checksums                                      true   pending-reboot
innodb_log_compressed_pages                               true   pending-reboot
innodb_log_file_size                                      true   pending-reboot
innodb_log_group_home_dir                                 false  pending-reboot
innodb_log_write_ahead_size                               true   pending-reboot
innodb_lru_scan_depth                                     true   pending-reboot
innodb_max_dirty_pages_pct                                true   pending-reboot
innodb_max_dirty_pages_pct_lwm                            true   pending-reboot
innodb_max_purge_lag                                      true   pending-reboot
innodb_max_purge_lag_delay                                true   pending-reboot
innodb_max_undo_log_size                                  true   pending-reboot
innodb_monitor_disable                                    true   pending-reboot
innodb_monitor_enable                                     true   pending-reboot
innodb_monitor_reset                                      true   pending-reboot
innodb_monitor_reset_all                                  true   pending-reboot
innodb_old_blocks_pct                                     true   pending-reboot
innodb_old_blocks_time                                    true   pending-reboot
innodb_online_alter_log_max_size                          true   pending-reboot
innodb_open_files                                         true   pending-reboot
innodb_optimize_fulltext_only                             true   pending-reboot
innodb_page_cleaners                                      true   pending-reboot
innodb_page_size                                          false  pending-reboot
innodb_print_all_deadlocks                                true   pending-reboot
innodb_purge_batch_size                                   true   pending-reboot
innodb_purge_rseg_truncate_frequency                      true   pending-reboot
innodb_purge_threads                                      true   pending-reboot
innodb_random_read_ahead                                  true   pending-reboot
innodb_read_ahead_threshold                               true   pending-reboot
innodb_read_io_threads                                    true   pending-reboot
innodb_read_only                                          false  pending-reboot
innodb_replication_delay                                  true   pending-reboot
innodb_rollback_on_timeout                                true   pending-reboot
innodb_rollback_segments                                  true   pending-reboot
innodb_sort_buffer_size                                   true   pending-reboot
innodb_spin_wait_delay                                    true   pending-reboot
innodb_stats_auto_recalc                                  true   pending-reboot
innodb_stats_method                                       true   pending-reboot
innodb_stats_on_metadata                                  true   pending-reboot
innodb_stats_persistent                                   true   pending-reboot
innodb_stats_persistent_sample_pages                      true   pending-reboot
innodb_stats_transient_sample_pages                       true   pending-reboot
innodb_status_output                                      true   pending-reboot
innodb_status_output_locks                                true   pending-reboot
innodb_strict_mode                                        true   pending-reboot
innodb_support_xa                                         true   pending-reboot
innodb_sync_array_size                                    true   pending-reboot
innodb_sync_spin_loops                                    true   pending-reboot
innodb_table_locks                                        true   pending-reboot
innodb_temp_data_file_path                                false  pending-reboot
innodb_thread_concurrency                                 true   pending-reboot
innodb_thread_sleep_delay                                 true   pending-reboot
innodb_undo_directory                                     false  pending-reboot
innodb_undo_log_truncate                                  true   pending-reboot
innodb_undo_logs                                          true   pending-reboot
innodb_undo_tablespaces                                   false  pending-reboot
innodb_use_native_aio                                     true   pending-reboot
innodb_write_io_threads                                   true   pending-reboot
interactive_timeout                                       true   pending-reboot
internal_tmp_disk_storage_engine                          true   pending-reboot
join_buffer_size                                          true   pending-reboot
keep_files_on_create                                      true   pending-reboot
key_buffer_size                                           true   pending-reboot
key_cache_age_threshold                                   true   pending-reboot
key_cache_block_size                                      true   pending-reboot
key_cache_division_limit                                  true   pending-reboot
lc_time_names                                             true   pending-reboot
local_infile                                              true   pending-reboot
lock_wait_timeout                                         true   pending-reboot
log-bin                                                   false  pending-reboot
log_bin_trust_function_creators                           true   pending-reboot
log_bin_use_v1_row_events                                 true   pending-reboot
log_builtin_as_identified_by_password                     true   pending-reboot
log_error                                                 false  pending-reboot
log_error_verbosity                                       true   pending-reboot
log_output                                                true   pending-reboot
log_queries_not_using_indexes                             true   pending-reboot
log_slave_updates                                         false  pending-reboot
log_slow_admin_statements                                 true   pending-reboot
log_slow_slave_statements                                 true   pending-reboot
log_statements_unsafe_for_binlog                          false  pending-reboot
log_syslog                                                false  pending-reboot
log_syslog_facility                                       false  pending-reboot
log_syslog_include_pid                                    false  pending-reboot
log_syslog_tag                                            false  pending-reboot
log_throttle_queries_not_using_indexes                    true   pending-reboot
log_timestamps                                            true   pending-reboot
log_warnings                                              true   pending-reboot
long_query_time                                           true   pending-reboot
low_priority_updates                                      true   pending-reboot
lower_case_table_names                                    true   pending-reboot
master-info-repository                                    true   pending-reboot
master_verify_checksum                                    true   pending-reboot
max_allowed_packet                                        true   pending-reboot
max_binlog_cache_size                                     true   pending-reboot
max_binlog_size                                           false  pending-reboot
max_binlog_stmt_cache_size                                true   pending-reboot
max_connect_errors                                        true   pending-reboot
max_connections                                           true   pending-reboot
max_delayed_threads                                       true   pending-reboot
max_digest_length                                         false  pending-reboot
max_error_count                                           true   pending-reboot
max_execution_time                                        true   pending-reboot
max_heap_table_size                                       true   pending-reboot
max_insert_delayed_threads                                true   pending-reboot
max_join_size                                             true   pending-reboot
max_length_for_sort_data                                  true   pending-reboot
max_points_in_geometry                                    true   pending-reboot
max_prepared_stmt_count                                   true   pending-reboot
max_seeks_for_key                                         true   pending-reboot
max_sort_length                                           true   pending-reboot
max_sp_recursion_depth                                    true   pending-reboot
max_tmp_tables                                            true   pending-reboot
max_user_connections                                      true   pending-reboot
max_write_lock_count                                      true   pending-reboot
mecab_rc_file                                             false  pending-reboot
metadata_locks_cache_size                                 true   pending-reboot
min_examined_row_limit                                    true   pending-reboot
myisam_data_pointer_size                                  true   pending-reboot
myisam_max_sort_file_size                                 true   pending-reboot
myisam_mmap_size                                          true   pending-reboot
myisam_sort_buffer_size                                   true   pending-reboot
myisam_stats_method                                       true   pending-reboot
myisam_use_mmap                                           true   pending-reboot
mysql_native_password_proxy_users                         true   pending-reboot
net_buffer_length                                         true   pending-reboot
net_read_timeout                                          true   pending-reboot
net_retry_count                                           true   pending-reboot
net_write_timeout                                         true   pending-reboot
ngram_token_size                                          true   pending-reboot
offline_mode                                              false  pending-reboot
old-style-user-limits                                     true   pending-reboot
old_passwords                                             true   pending-reboot
optimizer_prune_level                                     true   pending-reboot
optimizer_search_depth                                    true   pending-reboot
optimizer_switch                                          true   pending-reboot
optimizer_trace                                           true   pending-reboot
optimizer_trace_features                                  true   pending-reboot
optimizer_trace_limit                                     true   pending-reboot
optimizer_trace_max_mem_size                              true   pending-reboot
optimizer_trace_offset                                    true   pending-reboot
performance_schema                                        true   pending-reboot
performance_schema_accounts_size                          true   pending-reboot
performance_schema_digests_size                           true   pending-reboot
performance_schema_events_stages_history_long_size        true   pending-reboot
performance_schema_events_stages_history_size             true   pending-reboot
performance_schema_events_statements_history_long_size    true   pending-reboot
performance_schema_events_statements_history_size         true   pending-reboot
performance_schema_events_transactions_history_long_size  true   pending-reboot
performance_schema_events_transactions_history_size       true   pending-reboot
performance_schema_events_waits_history_long_size         true   pending-reboot
performance_schema_events_waits_history_size              true   pending-reboot
performance_schema_hosts_size                             true   pending-reboot
performance_schema_max_cond_classes                       true   pending-reboot
performance_schema_max_cond_instances                     true   pending-reboot
performance_schema_max_digest_length                      true   pending-reboot
performance_schema_max_file_classes                       true   pending-reboot
performance_schema_max_file_handles                       true   pending-reboot
performance_schema_max_file_instances                     true   pending-reboot
performance_schema_max_index_stat                         true   pending-reboot
performance_schema_max_memory_classes                     true   pending-reboot
performance_schema_max_metadata_locks                     true   pending-reboot
performance_schema_max_mutex_classes                      true   pending-reboot
performance_schema_max_mutex_instances                    true   pending-reboot
performance_schema_max_prepared_statements_instances      true   pending-reboot
performance_schema_max_program_instances                  true   pending-reboot
performance_schema_max_rwlock_classes                     true   pending-reboot
performance_schema_max_rwlock_instances                   true   pending-reboot
performance_schema_max_socket_classes                     true   pending-reboot
performance_schema_max_socket_instances                   true   pending-reboot
performance_schema_max_sql_text_length                    true   pending-reboot
performance_schema_max_stage_classes                      true   pending-reboot
performance_schema_max_statement_classes                  true   pending-reboot
performance_schema_max_statement_stack                    true   pending-reboot
performance_schema_max_table_handles                      true   pending-reboot
performance_schema_max_table_instances                    true   pending-reboot
performance_schema_max_table_lock_stat                    true   pending-reboot
performance_schema_max_thread_classes                     true   pending-reboot
performance_schema_max_thread_instances                   true   pending-reboot
performance_schema_session_connect_attrs_size             true   pending-reboot
performance_schema_setup_actors_size                      true   pending-reboot
performance_schema_setup_objects_size                     true   pending-reboot
performance_schema_users_size                             true   pending-reboot
pid_file                                                  false  pending-reboot
plugin_dir                                                false  pending-reboot
port                                                      false  pending-reboot
preload_buffer_size                                       true   pending-reboot
profiling_history_size                                    true   pending-reboot
query_alloc_block_size                                    true   pending-reboot
query_cache_limit                                         true   pending-reboot
query_cache_min_res_unit                                  true   pending-reboot
query_cache_size                                          true   pending-reboot
query_cache_type                                          true   pending-reboot
query_cache_wlock_invalidate                              true   pending-reboot
query_prealloc_size                                       true   pending-reboot
range_alloc_block_size                                    true   pending-reboot
range_optimizer_max_mem_size                              true   pending-reboot
read_buffer_size                                          true   pending-reboot
read_only                                                 true   pending-reboot
read_rnd_buffer_size                                      true   pending-reboot
relay-log                                                 false  pending-reboot
relay_log_info_repository                                 true   pending-reboot
relay_log_recovery                                        false  pending-reboot
require_secure_transport                                  false  pending-reboot
rpl_semi_sync_master_wait_for_slave_count                 false  pending-reboot
rpl_semi_sync_master_wait_point                           false  pending-reboot
rpl_stop_slave_timeout                                    false  pending-reboot
safe-user-create                                          true   pending-reboot
secure_auth                                               false  pending-reboot
secure_file_priv                                          false  pending-reboot
server_id                                                 false  pending-reboot
session_track_gtids                                       true   pending-reboot
session_track_schema                                      true   pending-reboot
session_track_state_change                                true   pending-reboot
session_track_system_variables                            true   pending-reboot
session_track_transaction_info                            true   pending-reboot
sha256_password_auto_generate_rsa_keys                    false  pending-reboot
sha256_password_proxy_users                               true   pending-reboot
show_compatibility_56                                     true   pending-reboot
show_old_temporals                                        true   pending-reboot
skip-character-set-client-handshake                       true   pending-reboot
skip-slave-start                                          false  pending-reboot
skip_external_locking                                     false  pending-reboot
skip_name_resolve                                         true   pending-reboot
skip_show_database                                        true   pending-reboot
slave_allow_batching                                      true   pending-reboot
slave_checkpoint_group                                    true   pending-reboot
slave_checkpoint_period                                   true   pending-reboot
slave_compressed_protocol                                 true   pending-reboot
slave_net_timeout                                         true   pending-reboot
slave_parallel_type                                       true   pending-reboot
slave_parallel_workers                                    true   pending-reboot
slave_pending_jobs_size_max                               true   pending-reboot
slave_preserve_commit_order                               true   pending-reboot
slave_rows_search_algorithms                              true   pending-reboot
slave_sql_verify_checksum                                 true   pending-reboot
slave_transaction_retries                                 true   pending-reboot
slave_type_conversions                                    true   pending-reboot
slow_launch_time                                          true   pending-reboot
slow_query_log                                            true   pending-reboot
slow_query_log_file                                       false  pending-reboot
socket                                                    false  pending-reboot
sort_buffer_size                                          true   pending-reboot
sql_mode                                                  true   pending-reboot
sql_select_limit                                          true   pending-reboot
stored_program_cache                                      true   pending-reboot
super_read_only                                           false  pending-reboot
sync_binlog                                               true   pending-reboot
sync_frm                                                  true   pending-reboot
sync_master_info                                          true   pending-reboot
sync_relay_log                                            true   pending-reboot
sync_relay_log_info                                       true   pending-reboot
sysdate-is-now                                            true   pending-reboot
table_definition_cache                                    true   pending-reboot
table_open_cache                                          true   pending-reboot
table_open_cache_instances                                true   pending-reboot
temp-pool                                                 true   pending-reboot
thread_cache_size                                         true   pending-reboot
thread_stack                                              true   pending-reboot
time_zone                                                 true   pending-reboot
tls_version                                               true   pending-reboot
tmp_table_size                                            true   pending-reboot
tmpdir                                                    false  pending-reboot
transaction_alloc_block_size                              true   pending-reboot
transaction_prealloc_size                                 true   pending-reboot
transaction_write_set_extraction                          false  pending-reboot
tx_isolation                                              true   pending-reboot
updatable_views_with_limit                                true   pending-reboot
validate-password                                         false  pending-reboot
validate_password_dictionary_file                         false  pending-reboot
validate_password_length                                  false  pending-reboot
validate_password_mixed_case_count                        false  pending-reboot
validate_password_number_count                            false  pending-reboot
validate_password_policy                                  false  pending-reboot
validate_password_special_char_count                      false  pending-reboot
wait_timeout                                              true   pending-reboot

default.postgres9.5

Parameter Name                          IsModifiable ApplyMethod
application_name                        true   pending-reboot
archive_command                         false  pending-reboot
archive_timeout                         false  pending-reboot
array_nulls                             true   pending-reboot
authentication_timeout                  true   pending-reboot
auto_explain.log_analyze                true   pending-reboot
auto_explain.log_buffers                true   pending-reboot
auto_explain.log_format                 true   pending-reboot
auto_explain.log_min_duration           true   pending-reboot
auto_explain.log_nested_statements      true   pending-reboot
auto_explain.log_timing                 true   pending-reboot
auto_explain.log_triggers               true   pending-reboot
auto_explain.log_verbose                true   pending-reboot
autovacuum                              true   pending-reboot
autovacuum_analyze_scale_factor         true   pending-reboot
autovacuum_analyze_threshold            true   pending-reboot
autovacuum_freeze_max_age               true   pending-reboot
autovacuum_max_workers                  true   pending-reboot
autovacuum_multixact_freeze_max_age     true   pending-reboot
autovacuum_naptime                      true   pending-reboot
autovacuum_vacuum_cost_delay            true   pending-reboot
autovacuum_vacuum_cost_limit            true   pending-reboot
autovacuum_vacuum_scale_factor          true   pending-reboot
autovacuum_vacuum_threshold             true   pending-reboot
autovacuum_work_mem                     true   pending-reboot
backslash_quote                         true   pending-reboot
bgwriter_delay                          true   pending-reboot
bgwriter_lru_maxpages                   true   pending-reboot
bgwriter_lru_multiplier                 true   pending-reboot
bytea_output                            true   pending-reboot
check_function_bodies                   true   pending-reboot
checkpoint_completion_target            true   pending-reboot
checkpoint_timeout                      true   pending-reboot
checkpoint_warning                      true   pending-reboot
client_encoding                         true   pending-reboot
client_min_messages                     true   pending-reboot
commit_delay                            true   pending-reboot
commit_siblings                         true   pending-reboot
config_file                             false  pending-reboot
constraint_exclusion                    true   pending-reboot
cpu_index_tuple_cost                    true   pending-reboot
cpu_operator_cost                       true   pending-reboot
cpu_tuple_cost                          true   pending-reboot
cursor_tuple_fraction                   true   pending-reboot
data_directory                          false  pending-reboot
datestyle                               true   pending-reboot
db_user_namespace                       false  pending-reboot
deadlock_timeout                        true   pending-reboot
debug_pretty_print                      true   pending-reboot
debug_print_parse                       true   pending-reboot
debug_print_plan                        true   pending-reboot
debug_print_rewritten                   true   pending-reboot
default_statistics_target               true   pending-reboot
default_tablespace                      true   pending-reboot
default_transaction_deferrable          true   pending-reboot
default_transaction_isolation           true   pending-reboot
default_transaction_read_only           true   pending-reboot
default_with_oids                       true   pending-reboot
effective_cache_size                    true   pending-reboot
effective_io_concurrency                true   pending-reboot
enable_bitmapscan                       true   pending-reboot
enable_hashagg                          true   pending-reboot
enable_hashjoin                         true   pending-reboot
enable_indexonlyscan                    true   pending-reboot
enable_indexscan                        true   pending-reboot
enable_material                         true   pending-reboot
enable_mergejoin                        true   pending-reboot
enable_nestloop                         true   pending-reboot
enable_seqscan                          true   pending-reboot
enable_sort                             true   pending-reboot
enable_tidscan                          true   pending-reboot
escape_string_warning                   true   pending-reboot
exit_on_error                           false  pending-reboot
extra_float_digits                      true   pending-reboot
from_collapse_limit                     true   pending-reboot
fsync                                   false  pending-reboot
full_page_writes                        false  pending-reboot
geqo                                    true   pending-reboot
geqo_effort                             true   pending-reboot
geqo_generations                        true   pending-reboot
geqo_pool_size                          true   pending-reboot
geqo_seed                               true   pending-reboot
geqo_selection_bias                     true   pending-reboot
geqo_threshold                          true   pending-reboot
gin_fuzzy_search_limit                  true   pending-reboot
gin_pending_list_limit                  true   pending-reboot
hba_file                                false  pending-reboot
hot_standby_feedback                    true   pending-reboot
huge_pages                              true   pending-reboot
ident_file                              false  pending-reboot
intervalstyle                           true   pending-reboot
join_collapse_limit                     true   pending-reboot
lc_messages                             true   pending-reboot
lc_monetary                             true   pending-reboot
lc_numeric                              true   pending-reboot
lc_time                                 true   pending-reboot
listen_addresses                        false  pending-reboot
lo_compat_privileges                    false  pending-reboot
log_autovacuum_min_duration             true   pending-reboot
log_checkpoints                         true   pending-reboot
log_connections                         true   pending-reboot
log_destination                         false  pending-reboot
log_directory                           false  pending-reboot
log_disconnections                      true   pending-reboot
log_duration                            true   pending-reboot
log_error_verbosity                     true   pending-reboot
log_executor_stats                      true   pending-reboot
log_file_mode                           false  pending-reboot
log_filename                            true   pending-reboot
log_hostname                            true   pending-reboot
log_line_prefix                         false  pending-reboot
log_lock_waits                          true   pending-reboot
log_min_duration_statement              true   pending-reboot
log_min_error_statement                 true   pending-reboot
log_min_messages                        true   pending-reboot
log_parser_stats                        true   pending-reboot
log_planner_stats                       true   pending-reboot
log_replication_commands                true   pending-reboot
log_rotation_age                        true   pending-reboot
log_rotation_size                       true   pending-reboot
log_statement                           true   pending-reboot
log_statement_stats                     true   pending-reboot
log_temp_files                          true   pending-reboot
log_timezone                            false  pending-reboot
log_truncate_on_rotation                false  pending-reboot
logging_collector                       false  pending-reboot
maintenance_work_mem                    true   pending-reboot
max_connections                         true   pending-reboot
max_files_per_process                   true   pending-reboot
max_locks_per_transaction               true   pending-reboot
max_pred_locks_per_transaction          true   pending-reboot
max_prepared_transactions               true   pending-reboot
max_replication_slots                   true   pending-reboot
max_stack_depth                         true   pending-reboot
max_standby_archive_delay               true   pending-reboot
max_standby_streaming_delay             true   pending-reboot
max_wal_senders                         true   pending-reboot
max_wal_size                            true   pending-reboot
min_wal_size                            true   pending-reboot
operator_precedence_warning             true   pending-reboot
password_encryption                     false  pending-reboot
pg_hint_plan.debug_print                true   pending-reboot
pg_hint_plan.enable_hint                true   pending-reboot
pg_hint_plan.enable_hint_table          true   pending-reboot
pg_hint_plan.message_level              true   pending-reboot
pg_hint_plan.parse_messages             true   pending-reboot
pg_stat_statements.max                  true   pending-reboot
pg_stat_statements.save                 true   pending-reboot
pg_stat_statements.track                true   pending-reboot
pg_stat_statements.track_utility        true   pending-reboot
pgaudit.log                             true   pending-reboot
pgaudit.log_catalog                     true   pending-reboot
pgaudit.log_level                       true   pending-reboot
pgaudit.log_parameter                   true   pending-reboot
pgaudit.log_relation                    true   pending-reboot
pgaudit.log_statement_once              true   pending-reboot
pgaudit.role                            true   pending-reboot
port                                    false  pending-reboot
postgis.gdal_enabled_drivers            true   pending-reboot
quote_all_identifiers                   true   pending-reboot
random_page_cost                        true   pending-reboot
rds.custom_dns_resolution               true   pending-reboot
rds.extensions                          false  pending-reboot
rds.force_admin_logging_level           true   pending-reboot
rds.force_autovacuum_logging_level      true   pending-reboot
rds.force_ssl                           true   pending-reboot
rds.log_retention_period                true   pending-reboot
rds.logical_replication                 true   pending-reboot
rds.max_tcp_buffers                     false  pending-reboot
rds.pg_stat_ramdisk_size                true   pending-reboot
rds.rds_superuser_reserved_connections  true   pending-reboot
rds.superuser_variables                 false  pending-reboot
restart_after_crash                     false  pending-reboot
row_security                            true   pending-reboot
search_path                             true   pending-reboot
seq_page_cost                           true   pending-reboot
server_encoding                         false  pending-reboot
session_replication_role                true   pending-reboot
shared_buffers                          true   pending-reboot
shared_preload_libraries                true   pending-reboot
sql_inheritance                         true   pending-reboot
ssl                                     true   pending-reboot
ssl_ca_file                             false  pending-reboot
ssl_cert_file                           false  pending-reboot
ssl_ciphers                             false  pending-reboot
ssl_key_file                            false  pending-reboot
standard_conforming_strings             true   pending-reboot
statement_timeout                       true   pending-reboot
stats_temp_directory                    false  pending-reboot
superuser_reserved_connections          false  pending-reboot
synchronize_seqscans                    true   pending-reboot
synchronous_commit                      true   pending-reboot
syslog_facility                         false  pending-reboot
tcp_keepalives_count                    true   pending-reboot
tcp_keepalives_idle                     true   pending-reboot
tcp_keepalives_interval                 true   pending-reboot
temp_buffers                            true   pending-reboot
temp_tablespaces                        true   pending-reboot
timezone                                true   pending-reboot
track_activities                        true   pending-reboot
track_activity_query_size               true   pending-reboot
track_commit_timestamp                  true   pending-reboot
track_counts                            true   pending-reboot
track_functions                         true   pending-reboot
track_io_timing                         true   pending-reboot
transaction_deferrable                  true   pending-reboot
transaction_read_only                   true   pending-reboot
transform_null_equals                   true   pending-reboot
unix_socket_directories                 false  pending-reboot
unix_socket_group                       false  pending-reboot
unix_socket_permissions                 false  pending-reboot
update_process_title                    true   pending-reboot
vacuum_cost_delay                       true   pending-reboot
vacuum_cost_limit                       true   pending-reboot
vacuum_cost_page_dirty                  true   pending-reboot
vacuum_cost_page_hit                    true   pending-reboot
vacuum_cost_page_miss                   true   pending-reboot
vacuum_defer_cleanup_age                true   pending-reboot
vacuum_freeze_min_age                   true   pending-reboot
vacuum_freeze_table_age                 true   pending-reboot
vacuum_multixact_freeze_min_age         true   pending-reboot
vacuum_multixact_freeze_table_age       true   pending-reboot
wal_buffers                             true   pending-reboot
wal_compression                         true   pending-reboot
wal_keep_segments                       true   pending-reboot
wal_receiver_status_interval            true   pending-reboot
wal_receiver_timeout                    true   pending-reboot
wal_sender_timeout                      true   pending-reboot
wal_sync_method                         false  pending-reboot
wal_writer_delay                        true   pending-reboot
work_mem                                true   pending-reboot
xmlbinary                               true   pending-reboot
xmloption                               true   pending-reboot

default.oracle-ee-12.1

Parameter Name                                       IsModifiable ApplyMethod
_allow_level_without_connect_by              true   pending-reboot
_always_semi_join                            true   pending-reboot
_awr_mmon_deep_purge_all_expired             true   pending-reboot
_b_tree_bitmap_plans                         true   pending-reboot
_cursor_features_enabled                     true   pending-reboot
_cursor_obsolete_threshold                   true   pending-reboot
_db_block_prefetch_limit                     true   pending-reboot
_db_block_prefetch_quota                     true   pending-reboot
_db_file_noncontig_mblock_read_count         true   pending-reboot
_disable_function_based_index                true   pending-reboot
_enable_shared_pool_durations                true   pending-reboot
_enable_space_preallocation                  true   pending-reboot
_fast_full_scan_enabled                      true   pending-reboot
_fix_control                                 true   pending-reboot
_gby_hash_aggregation_enabled                true   pending-reboot
_gc_defer_time                               false  pending-reboot
_grant_secure_role                           true   pending-reboot
_ignore_desc_in_index                        true   pending-reboot
_index_join_enabled                          true   pending-reboot
_index_partition_large_extents               true   pending-reboot
_kks_obsolete_dump_threshold                 true   pending-reboot
_ktb_debug_flags                             true   pending-reboot
_like_with_bind_as_equality                  true   pending-reboot
_mutex_wait_scheme                           true   pending-reboot
_mutex_wait_time                             true   pending-reboot
_mv_refresh_use_hash_sj                      true   pending-reboot
_mv_refresh_use_stats                        true   pending-reboot
_no_or_expansion                             true   pending-reboot
_optim_peek_user_binds                       true   pending-reboot
_optimizer_adaptive_cursor_sharing           true   pending-reboot
_optimizer_ads_use_result_cache              true   pending-reboot
_optimizer_aggr_groupby_elim                 true   pending-reboot
_optimizer_autostats_job                     true   pending-reboot
_optimizer_batch_table_access_by_rowid       true   pending-reboot
_optimizer_cartesian_enabled                 true   pending-reboot
_optimizer_cost_based_transformation         true   pending-reboot
_optimizer_dsdir_usage_control               true   pending-reboot
_optimizer_enhanced_filter_push              true   pending-reboot
_optimizer_extended_cursor_sharing           true   pending-reboot
_optimizer_extended_cursor_sharing_rel       true   pending-reboot
_optimizer_gather_feedback                   true   pending-reboot
_optimizer_invalidation_period               true   pending-reboot
_optimizer_join_elimination_enabled          true   pending-reboot
_optimizer_join_sel_sanity_check             true   pending-reboot
_optimizer_max_permutations                  true   pending-reboot
_optimizer_mjc_enabled                       true   pending-reboot
_optimizer_order_by_elimination_enabled      true   pending-reboot
_optimizer_partial_join_eval                 true   pending-reboot
_optimizer_reduce_groupby_key                true   pending-reboot
_optimizer_skip_scan_enabled                 true   pending-reboot
_optimizer_sortmerge_join_enabled            true   pending-reboot
_optimizer_use_feedback                      true   pending-reboot
_orph_cln_interval                           true   pending-reboot
_partition_large_extents                     true   pending-reboot
_partition_view_enabled                      true   pending-reboot
_pred_move_around                            true   pending-reboot
_report_capture_cycle_time                   true   pending-reboot
_rollback_segment_count                      true   pending-reboot
_rowsets_enabled                             true   pending-reboot
_securefiles_concurrency_estimate            true   pending-reboot
_smu_debug_mode                              true   pending-reboot
_sort_elimination_cost_ratio                 true   pending-reboot
_sql_plan_directive_mgmt_control             true   pending-reboot
_sqlexec_progression_cost                    true   pending-reboot
_sqlmon_max_planlines                        true   pending-reboot
_suppress_identifiers_on_dupkey              true   pending-reboot
_unnest_subquery                             true   pending-reboot
_use_single_log_writer                       true   pending-reboot
aq_tm_processes                              true   pending-reboot
archive_lag_target                           true   pending-reboot
audit_file_dest                              false  pending-reboot
audit_sys_operations                         false  pending-reboot
audit_syslog_level                           false  pending-reboot
audit_trail                                  true   pending-reboot
background_core_dump                         true   pending-reboot
background_dump_dest                         false  pending-reboot
bitmap_merge_area_size                       true   pending-reboot
blank_trimming                               true   pending-reboot
buffer_pool_keep                             true   pending-reboot
buffer_pool_recycle                          true   pending-reboot
circuits                                     true   pending-reboot
client_result_cache_lag                      true   pending-reboot
client_result_cache_size                     true   pending-reboot
commit_logging                               true   pending-reboot
commit_point_strength                        true   pending-reboot
commit_wait                                  true   pending-reboot
commit_write                                 false  pending-reboot
compatible                                   true   pending-reboot
connection_brokers                           false  pending-reboot
control_file_record_keep_time                true   pending-reboot
control_files                                false  pending-reboot
control_management_pack_access               true   pending-reboot
core_dump_dest                               false  pending-reboot
cpu_count                                    true   pending-reboot
create_bitmap_area_size                      true   pending-reboot
create_stored_outlines                       true   pending-reboot
cursor_bind_capture_destination              true   pending-reboot
cursor_sharing                               true   pending-reboot
cursor_space_for_time                        true   pending-reboot
db_16k_cache_size                            true   pending-reboot
db_2k_cache_size                             true   pending-reboot
db_32k_cache_size                            true   pending-reboot
db_4k_cache_size                             true   pending-reboot
db_8k_cache_size                             false  pending-reboot
db_big_table_cache_percent_target            true   pending-reboot
db_block_buffers                             true   pending-reboot
db_block_checking                            true   pending-reboot
db_block_checksum                            true   pending-reboot
db_block_size                                false  pending-reboot
db_cache_advice                              true   pending-reboot
db_cache_size                                true   pending-reboot
db_create_file_dest                          false  pending-reboot
db_create_online_log_dest_1                  false  pending-reboot
db_create_online_log_dest_2                  false  pending-reboot
db_create_online_log_dest_3                  false  pending-reboot
db_create_online_log_dest_4                  false  pending-reboot
db_create_online_log_dest_5                  false  pending-reboot
db_domain                                    true   pending-reboot
db_file_multiblock_read_count                true   pending-reboot
db_file_name_convert                         false  pending-reboot
db_files                                     true   pending-reboot
db_flashback_retention_target                true   pending-reboot
db_index_compression_inheritance             true   pending-reboot
db_keep_cache_size                           true   pending-reboot
db_lost_write_protect                        true   pending-reboot
db_name                                      false  pending-reboot
db_recovery_file_dest                        false  pending-reboot
db_recovery_file_dest_size                   true   pending-reboot
db_recycle_cache_size                        true   pending-reboot
db_securefile                                true   pending-reboot
db_ultra_safe                                true   pending-reboot
db_unique_name                               false  pending-reboot
db_unrecoverable_scn_tracking                false  pending-reboot
db_writer_processes                          true   pending-reboot
dbfips_140                                   true   pending-reboot
dbwr_io_slaves                               false  pending-reboot
ddl_lock_timeout                             true   pending-reboot
deferred_segment_creation                    true   pending-reboot
dg_broker_config_file1                       false  pending-reboot
dg_broker_config_file2                       false  pending-reboot
dg_broker_start                              false  pending-reboot
diagnostic_dest                              false  pending-reboot
disk_asynch_io                               false  pending-reboot
dispatchers                                  true   pending-reboot
distributed_lock_timeout                     true   pending-reboot
dml_locks                                    true   pending-reboot
dst_upgrade_insert_conv                      false  pending-reboot
enable_ddl_logging                           true   pending-reboot
enable_goldengate_replication                true   pending-reboot
enable_pluggable_database                    false  pending-reboot
event                                        false  pending-reboot
fal_client                                   false  pending-reboot
fal_server                                   false  pending-reboot
fast_start_mttr_target                       true   pending-reboot
fast_start_parallel_rollback                 true   pending-reboot
filesystemio_options                         false  pending-reboot
fixed_date                                   false  pending-reboot
gcs_server_processes                         false  pending-reboot
global_context_pool_size                     true   pending-reboot
global_names                                 true   pending-reboot
heat_map                                     true   pending-reboot
hs_autoregister                              true   pending-reboot
ifile                                        false  pending-reboot
inmemory_clause_default                      true   pending-reboot
inmemory_clause_default_memcompress          true   pending-reboot
inmemory_clause_default_priority             true   pending-reboot
inmemory_force                               true   pending-reboot
inmemory_max_populate_servers                false  pending-reboot
inmemory_query                               true   pending-reboot
inmemory_size                                true   pending-reboot
inmemory_trickle_repopulate_servers_percent  true   pending-reboot
instance_name                                false  pending-reboot
java_jit_enabled                             false  pending-reboot
java_max_sessionspace_size                   false  pending-reboot
java_pool_size                               false  pending-reboot
java_soft_sessionspace_limit                 false  pending-reboot
job_queue_processes                          true   pending-reboot
large_pool_size                              true   pending-reboot
ldap_directory_access                        false  pending-reboot
ldap_directory_sysauth                       false  pending-reboot
license_max_sessions                         true   pending-reboot
license_max_users                            true   pending-reboot
license_sessions_warning                     true   pending-reboot
listener_networks                            false  pending-reboot
local_listener                               false  pending-reboot
lock_name_space                              true   pending-reboot
lock_sga                                     false  pending-reboot
log_archive_config                           false  pending-reboot
log_archive_dest                             false  pending-reboot
log_archive_dest_1                           false  pending-reboot
log_archive_dest_state_1                     false  pending-reboot
log_archive_format                           false  pending-reboot
log_archive_local_first                      false  pending-reboot
log_archive_max_processes                    true   pending-reboot
log_archive_min_succeed_dest                 true   pending-reboot
log_archive_trace                            true   pending-reboot
log_buffer                                   true   pending-reboot
log_checkpoint_interval                      true   pending-reboot
log_checkpoint_timeout                       true   pending-reboot
log_checkpoints_to_alert                     true   pending-reboot
log_file_name_convert                        false  pending-reboot
max_dispatchers                              true   pending-reboot
max_dump_file_size                           true   pending-reboot
max_enabled_roles                            false  pending-reboot
max_shared_servers                           true   pending-reboot
max_string_size                              false  pending-reboot
memory_max_target                            true   pending-reboot
memory_target                                true   pending-reboot
nls_date_format                              true   pending-reboot
nls_length_semantics                         true   pending-reboot
nls_nchar_conv_excp                          true   pending-reboot
nls_time_format                              true   pending-reboot
nls_time_tz_format                           true   pending-reboot
nls_timestamp_format                         true   pending-reboot
nls_timestamp_tz_format                      true   pending-reboot
noncdb_compatible                            true   pending-reboot
o7_dictionary_accessibility                  false  pending-reboot
object_cache_max_size_percent                true   pending-reboot
object_cache_optimal_size                    true   pending-reboot
olap_page_pool_size                          true   pending-reboot
open_cursors                                 true   pending-reboot
open_links                                   true   pending-reboot
open_links_per_instance                      true   pending-reboot
optimizer_adaptive_features                  true   pending-reboot
optimizer_adaptive_reporting_only            true   pending-reboot
optimizer_capture_sql_plan_baselines         true   pending-reboot
optimizer_dynamic_sampling                   true   pending-reboot
optimizer_features_enable                    true   pending-reboot
optimizer_index_caching                      true   pending-reboot
optimizer_index_cost_adj                     true   pending-reboot
optimizer_mode                               true   pending-reboot
optimizer_secure_view_merging                true   pending-reboot
optimizer_use_invisible_indexes              true   pending-reboot
optimizer_use_pending_statistics             true   pending-reboot
optimizer_use_sql_plan_baselines             true   pending-reboot
os_authent_prefix                            false  pending-reboot
os_roles                                     false  pending-reboot
parallel_adaptive_multi_user                 true   pending-reboot
parallel_automatic_tuning                    true   pending-reboot
parallel_degree_level                        true   pending-reboot
parallel_degree_limit                        true   pending-reboot
parallel_degree_policy                       true   pending-reboot
parallel_execution_message_size              true   pending-reboot
parallel_max_servers                         true   pending-reboot
parallel_min_servers                         true   pending-reboot
parallel_min_time_threshold                  true   pending-reboot
parallel_servers_target                      true   pending-reboot
parallel_threads_per_cpu                     true   pending-reboot
pdb_file_name_convert                        false  pending-reboot
permit_92_wrap_format                        true   pending-reboot
pga_aggregate_limit                          true   pending-reboot
pga_aggregate_target                         true   pending-reboot
plscope_settings                             true   pending-reboot
plsql_ccflags                                true   pending-reboot
plsql_code_type                              true   pending-reboot
plsql_debug                                  true   pending-reboot
plsql_optimize_level                         true   pending-reboot
plsql_v2_compatibility                       true   pending-reboot
plsql_warnings                               true   pending-reboot
processes                                    true   pending-reboot
processor_group_name                         false  pending-reboot
query_rewrite_enabled                        true   pending-reboot
query_rewrite_integrity                      true   pending-reboot
rdbms_server_dn                              false  pending-reboot
read_only_open_delayed                       false  pending-reboot
recovery_parallelism                         false  pending-reboot
recyclebin                                   true   pending-reboot
redo_transport_user                          false  pending-reboot
remote_dependencies_mode                     true   pending-reboot
remote_listener                              false  pending-reboot
remote_login_passwordfile                    false  pending-reboot
remote_os_authent                            false  pending-reboot
remote_os_roles                              false  pending-reboot
replication_dependency_tracking              true   pending-reboot
resource_limit                               true   pending-reboot
resource_manager_cpu_allocation              true   pending-reboot
resource_manager_plan                        true   pending-reboot
result_cache_max_result                      true   pending-reboot
result_cache_max_size                        true   pending-reboot
result_cache_mode                            true   pending-reboot
result_cache_remote_expiration               true   pending-reboot
resumable_timeout                            true   pending-reboot
rollback_segments                            false  pending-reboot
sec_case_sensitive_logon                     true   pending-reboot
sec_max_failed_login_attempts                true   pending-reboot
sec_protocol_error_further_action            true   pending-reboot
sec_protocol_error_trace_action              true   pending-reboot
sec_return_server_release_banner             true   pending-reboot
serial_reuse                                 true   pending-reboot
service_names                                false  pending-reboot
session_cached_cursors                       true   pending-reboot
session_max_open_files                       true   pending-reboot
sessions                                     true   pending-reboot
sga_max_size                                 true   pending-reboot
sga_target                                   true   pending-reboot
shadow_core_dump                             true   pending-reboot
shared_memory_address                        false  pending-reboot
shared_pool_reserved_size                    true   pending-reboot
shared_pool_size                             true   pending-reboot
shared_server_sessions                       true   pending-reboot
shared_servers                               true   pending-reboot
skip_unusable_indexes                        true   pending-reboot
smtp_out_server                              true   pending-reboot
sort_area_retained_size                      true   pending-reboot
sort_area_size                               true   pending-reboot
spatial_vector_acceleration                  true   pending-reboot
spfile                                       false  pending-reboot
sql92_security                               true   pending-reboot
sql_trace                                    true   pending-reboot
sqlnetora.default_sdu_size                   true   pending-reboot
sqlnetora.diag_adr_enabled                   true   pending-reboot
sqlnetora.recv_buf_size                      true   pending-reboot
sqlnetora.send_buf_size                      true   pending-reboot
sqlnetora.sqlnet.expire_time                 true   pending-reboot
sqlnetora.sqlnet.inbound_connect_timeout     true   pending-reboot
sqlnetora.sqlnet.outbound_connect_timeout    true   pending-reboot
sqlnetora.sqlnet.recv_timeout                true   pending-reboot
sqlnetora.sqlnet.send_timeout                true   pending-reboot
sqlnetora.tcp.connect_timeout                true   pending-reboot
sqlnetora.trace_level_server                 true   pending-reboot
sqltune_category                             true   pending-reboot
standby_archive_dest                         false  pending-reboot
standby_file_management                      false  pending-reboot
star_transformation_enabled                  true   pending-reboot
statistics_level                             true   pending-reboot
streams_pool_size                            true   pending-reboot
temp_undo_enabled                            true   pending-reboot
thread                                       false  pending-reboot
threaded_execution                           false  pending-reboot
timed_os_statistics                          true   pending-reboot
timed_statistics                             true   pending-reboot
trace_enabled                                true   pending-reboot
transactions                                 true   pending-reboot
transactions_per_rollback_segment            true   pending-reboot
undo_management                              false  pending-reboot
undo_retention                               true   pending-reboot
undo_tablespace                              true   pending-reboot
unified_audit_sga_queue_size                 true   pending-reboot
use_dedicated_broker                         false  pending-reboot
use_indirect_data_buffers                    false  pending-reboot
use_large_pages                              true   pending-reboot
user_dump_dest                               false  pending-reboot
utl_file_dir                                 false  pending-reboot
workarea_size_policy                         true   pending-reboot
xml_db_events                                false  pending-reboot

SQL Serverのdefault パラメータグループは、カラム表示が上手くできなかったので、一旦割愛。

Blog記事を書いたら非同期で自動的にAmazon Chime Roomにwebhookで投稿する

実現したいこと

  • Blogの記事を投稿したら、その内容がAmazon Chime Roomに自動で投稿されること
    • Amazon CloudWatch Eventを使って1時間に1回Lambdaを起動
    • LambdaがBlogのRSS Feedを取得して、最新の記事があれば、それをChime Roomに投稿する
    • Chime Roomには事前にinboundのwebhookを設定しておき、LambdaからHTTPでPOSTできるようにする

構成イメージ

f:id:kenjifunasaki:20181206205412p:plain

手順

1. Amazon ChimeでChime Roomを作成する

今回は事前にAmazon Chimeは利用済みで、Amazon Chime ApplicationもPCにインストール済み、すでにChimeにログイン、チャットが可能なものとします。まず最初にChime roomを作成します。
Chimeアプリ上で「File」→「New Chat Room」を選択します。

f:id:kenjifunasaki:20181206195310p:plain

Nameを記入後に、Createをクリックします。

f:id:kenjifunasaki:20181206195659p:plain

2. webhookの設定をする

作成したChime Room右上にある設定ボタンをクリックして、「Manage Webhook」を選択します。「New」を選択してwebhook名を記入してcreateを選択すると以下が表示されます。
f:id:kenjifunasaki:20181206200002p:plain

こちらにあるCopy Webhook URLを選択して、URLをメモしておきます。後程使います。

3. RSS Read用のLambda Functionを作成する

今回はPython 2.7を使用します。
f:id:kenjifunasaki:20181206200650p:plain

lambda_function.pyというファイルを作成します。中身は下記です。

import feedparser
import requests
import json
import datetime
from time import mktime


def lambda_handler(event, context):

    NewsFeed = feedparser.parse("http://[Blog SiteのRSSのURL]")

    print 'Number of RSS posts :', len(NewsFeed.entries)

    entry = NewsFeed.entries[0]

    print 'Post Title :',entry.title
    time = entry.published_parsed
    result = datetime.datetime.now() - datetime.datetime.fromtimestamp(mktime(time))

    s = result.total_seconds()

    if s < 3600:
        message = 'Title: ' + entry.title + '\r\n' + 'URL: ' + entry.link
        url = 'https://hooks.chime.aws/incomingwebhooks/xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx'

        payload = {"Content": message}
        headers = {'content-type': 'application/json'}
        response = requests.post(url, data=json.dumps(payload), headers=headers)
        return 'updated'
    else:
        return 'no updated'

    return {
        'message' : message
    }

こちらのファイルを作成後、必要なライブラリをpipでインストールします。

$ pip install feedparser -t .
$ pip install requests -t .

その後、先ほどのpythonのファイルを含めてzipで固めます。

$ zip -r lambda_function.zip ./*

AWS CLIで、このzipをアップします。(AWS CLIの設定は事前に設定済みとします。)

$ aws lambda update-function-code --function-name RSSReaderFunction --zip-file fileb://lambda_function.zip

aws configureコマンドを実行して、default regionは指定済みとします。

Lambda functionのアップデートが完了したら、AWS LambdaのManagement Consoleを見てみます。(事前にブログサイト側でもテスト記事の投稿をしておきます。今回のLambda functionは、BlogサイトのRSSを読み込んで、直近1時間以内に記事がpublishされれば、それをChime roomに投稿するため)
f:id:kenjifunasaki:20181206202434p:plain

ここではLambdaを実行するための"myEvent"を既に定義してありますが、以下のようにmyEventを作成しておきます。

f:id:kenjifunasaki:20181206202747p:plain

作成したLambda functionとイベントを使ってテストしてみます。
f:id:kenjifunasaki:20181206210209p:plain

無事テストが成功し、Chime roomにもwebhookで書き込まれたことが確認できました。
f:id:kenjifunasaki:20181206203432p:plain

あとは、このLambda FunctionをCloudWatch Eventで1時間に1回定期実行させます。

4. CloudWatch Eventで1時間に1回Lambda Functionをinvokeする

Amazon CloudWatchのManagement Consoleを開いて、CloudWatch Eventのルールを作成します。イベントソースにて「スケジュール」を選択し、1時間おきに動作する設定にします。ターゲットはLambda 関数で、作成したLambda Functionを選択します。
f:id:kenjifunasaki:20181206203901p:plain
その次の画面でルール名を入力して、「ルールの作成」をクリックします。
f:id:kenjifunasaki:20181206204144p:plain

作成したルールの状態が有効になっていることを確認できれば、1時間おきに、先ほどのRSSReaderFunctionが呼ばれ、1時間以内に記事がpublishされていれば、RSS Feedにより最新の記事のタイトルとリンクがChime roomにpostされます。

以上で完了です!

Cognito Identity PoolsのUnauthenticated Identity(認証されていないID)を使ってS3へアップロードする

実現するのは以下のイメージです。
f:id:kenjifunasaki:20181004165338p:plain

JavaScriptを使って、Cognito Identity Poolから必要なトークンを取得、トークンに含まれる一時的な認証情報を使って、S3へファイルをアップロードします。

前提条件

Cognito ID Poolを作成する

f:id:kenjifunasaki:20181004185340p:plain
IDプール名を入れて、認証されていないIDに対してアクセスを有効にします。

作成するプールのIDに割り当てるIAMロールを作成

f:id:kenjifunasaki:20181004185730p:plain

JavaScript用のコードの確認

f:id:kenjifunasaki:20181004190020p:plain
こちらにあるIdentityPoolIdは後程使います。

作成したIAMロールにS3の権限を与える

UnAuthRoleとAuthRoleが作成されているのが分かります。
f:id:kenjifunasaki:20181004190511p:plain

今回はUnAuthRoleを使うので、こちらにAmazonS3FullAccess権限を追加します。今回はテスト用にFullAccess権限を追加していますが、最小権限の権限を追加するようにしてください。
f:id:kenjifunasaki:20181004191445p:plain

JavaScriptファイルを作成する

s3upload-unauth.htmlを作成します。

<html>
<head>
<script type="text/javascript" src="https://sdk.amazonaws.com/js/aws-sdk-2.6.9.min.js"></script>
</head>
<body>
<input type='file' name='upload' id='upload-file'>
<button id='upload-button'>upload</button>
<div id="results"></div>

<script type="text/javascript">
var upload = document.getElementById('upload-button');
var results = document.getElementById('results');

upload.addEventListener('click', function() {
    var uploadFile = document.getElementById('upload-file');
    var file = uploadFile.files[0];
    if(file) {
        var params = {
            IdentityPoolId: "ap-northeast-1:xxxxxxxx-xxxxx-xxxxxx-xxxx-xxxxxxxxxx"
        };
        AWS.config.region = 'ap-northeast-1';
        AWS.config.credentials = new AWS.CognitoIdentityCredentials(params);
        AWS.config.credentials.get(function(err) {
            if (!err) {
                console.log(AWS.config.credentials.identityId);
                var bucket = new AWS.S3({params: {Bucket: 'mybucketname'}});
                var params1 = {Key: file.name, ContentType: file.type, Body: file};
                bucket.putObject(params1, function (err, data) {
                    results.innerHTML = err ? 'ERROR!' : 'UPLOADED.';
                });
            }
        });
    } else {
        results.innterHTML = 'Noting to upload.';
    }
}, false);
</script>
</body>
</html>

IdentityPoolIdの部分に作成したCognito IDプールのIDを入れます。さらに、mybucketnameの部分に自身のバケット名を入れます。

Apache Httpd Serverをインストールして、作成したJavaScriptを配置する

sudo yum install httpd -y
sudo service httpd start

/var/www/html配下に作成したs3upload-unauth.htmlを配置する。

S3へのアップロード

http:///s3upload-unauth.html へアクセスすると、以下のような画面が表示される。
f:id:kenjifunasaki:20181004193646p:plain

ファイルを選択してアップロードします。

f:id:kenjifunasaki:20181004194241p:plain

成功すると、以下のようにUPLOADと表示されます。上手くいかない場合はChromeであれば、ChromeのDeveloper Toolのコンソールを見るなどしてエラー内容を確認します。

S3の指定したバケットにで正しくアップロードされていることを確認できました!

このように、Cognito Identityを使って、一時的な認証情報を取得し、S3へアップロードすることができました。

AWS Systems Managerでパッチコンプライアンスのステータスを確認する

AWS Systems ManagerのエージェントをWindows EC2インスタンスにインストール済みで、マネージドインスタンスとして確認がとれているインスタンスのパッチコンプライアンスのステータスを確認してみたいと思います。

以下のi-0fc8232827e0748d1のマネージドインスタンスをベースにして見てみます。
f:id:kenjifunasaki:20180502184058p:plain

AWS Systems Managerにてコンプライアンスのステータスを確認するには、Systems Manager(SSM)のマネージメントコンソールにて、Complianceを選択します。
f:id:kenjifunasaki:20180502184335p:plain

こちらを見ると、私の環境で以前確認したインスタンスコンプライアンスステータスが見れますが、今回見ようとしているi-0fc8232827e0748d1はまだ何も表示されていません。

こちらの状態でAWS-RunPatchBaselineのコマンドで、引数をScanで指定して実行してみます。同じ画面の下部でScanを指定して、コマンドを実行します。
f:id:kenjifunasaki:20180502184707p:plain

AWS-RunPatchBaselineのコマンドでScanを実行した結果、成功と表示されました。
f:id:kenjifunasaki:20180502185149p:plain

実行した結果、以下のメッセージが出力されました。

Patch Summary for i-0fc8232827e0748d1

PatchGroup :

BaselineId : pb-04ba050f612fba3a6

SnapshotId : e2a05e73-f205-4959-88c9-c763bb3c63b2

OwnerInformation :

OperationType : Scan

OperationStartTime : 2018-05-02T09:47:31.5522091Z

OperationEndTime : 2018-05-02T09:47:47.0833793Z

InstalledCount : 1

InstalledOtherCount : 11

FailedCount : 0

MissingCount : 1

NotApplicableCount : 2403

EC2AMAZ-99HABA7 - PatchBaselineOperations Assessment Results - 2018-05-02T09:47:49.520

Scan found the following updates missing:

KB4093120

PatchBaselineOperaseion Assessment結果としては、一部Updateが不足しているようです。この状態でAWS Systems Managerのコンプライアンスの画面を見てみます。

f:id:kenjifunasaki:20180502185604p:plain

先ほどのコンプライアンススクリーンショットと比較してみてください。先ほどは表示されていなかったi-0fc8232827e0748d1のコンプライアンスステータスが表示されるようになり、かつPatchBaselineOperationに非準拠であるため、グラフで赤く表示されているのが分かります。

このように、AWS-RunPatchBaselineのScanを実行するだけで、自動でコンプライアンスのステータスを確認できるようになるようです。

以上で、パッチコンプライアンスのステータスを確認することができました。PatchBaselineのインストールの手順は前回の記事で紹介しているので、今回は割愛します。

AWS Systems ManagerでAWS-RunPatchBaselineをRun Commandで実行して、Windowsインスタンスにパッチを適用する

以前の記事にあるように、EC2 WindowsインスタンスAWS Systems Manager(SSM)のマネージドインスタンスとして登録してあるのを前提とします。

本記事では、このWindowsのマネージドインスタンスにSSMのRun CommandでAWS-RunPatchBaselineを実行してみます。

AWS-RunPatchBaselineでは引数として、ScanまたはInstallを選べます。
SSM ドキュメント AWS-RunPatchBaseline について - AWS Systems Manager

ですので、最初にScanを実行して、適用すべきパッチを確認した後で、Installを実行してみます。

AWS-RunPatchBaselineのScanの実行

SSMの画面で、Run Commandの画面を開いて、コマンドの実行を選択します。

f:id:kenjifunasaki:20180502114709p:plain

続いて、検索条件に「ドキュメントのプレフィックス名」で「等しい」でAWS-RunPatchBaselineを入力して、ドキュメントをフィルターします。表示されたAWS-RunPatchBaselineを選択します。
f:id:kenjifunasaki:20180502114722p:plain

同じ画面で、続いてターゲットインスタンスを指定します。
f:id:kenjifunasaki:20180502115726p:plain

さらに同じ画面で、コマンドのパラメータでScanを選択して、
f:id:kenjifunasaki:20180502115113p:plain

実行を選択します。

その後、進行中のステータスが表示されます。
f:id:kenjifunasaki:20180502120115p:plain

その後、実行が成功し、実行ターゲットであったマネージドインスタンスのリンクを開いてみると以下のように今回のAWS-RunPatchBaselineのコマンドの実行結果が表示されます。
f:id:kenjifunasaki:20180502120446p:plain

こちらのスクリーンショットの画面上部にあるプラグイン名 PatchLinuxのコマンドはステータスが成功にはなっていますが、出力を見ると、

Step execution skipped due to incompatible platform. Step name: PatchLinux

と表示され、Linuxのpatch適用はskipされたことがわかります。今回のターゲットはWindowsインスタンスのためです。

出力2を確認してみます。
f:id:kenjifunasaki:20180502120740p:plain

Scan found the following updates missing:

KB4093120

KB4093120のアップデートが不足しているようです。

記事執筆時点では、2018年5月2日ですが、2018年4月18日時点で出ている以下の修正が必要なようです。

https://support.microsoft.com/ja-jp/help/4093120/windows-10-update-kb4093120

AWS-RunPatchBaselineでInstallを実行してみる。

上記アップデートを実行してみます。

Scan時同様に、AWS Systems ManagerのRun Command画面でコマンドの実行を選択し、AWS-RunPatchBaselineのドキュメントを選択し、ターゲットのインスタンスも同様に選択します。そのうえでコマンドのパラメータはInstallを選択します。

f:id:kenjifunasaki:20180502121448p:plain

Installの実行開始後、しばらくアップデートに時間がかかり、その間はステータスが進行中になっています。実行が完了して、成功すると、以下のように表示されます。

f:id:kenjifunasaki:20180502180357p:plain

同じ画面でターゲットのインスタンスのリンクをクリックして
f:id:kenjifunasaki:20180502180544p:plain

実際のInstallの実行結果を確認します。
f:id:kenjifunasaki:20180502180624p:plain

KB4093120 Yes Success

インストールが問題なく実行完了できたことがわかりました。

Windows Server 2016 AMIを起動して、AWS Systems Managerでマネージドインスタンスとして管理する

AWSから提供されているWindows Server 2016のAMIには、デフォルトでAWS Systems Managet(SSM)のエージェントがインストールされています。SSMエージェントのパスは以下です。

C:\Program Files\Amazon\SSM\amazon-ssm-agent.exe

SSMエージェント用のIAMロールをこちらのEC2 Windowsインスタンスに割り当てておかないと、上記amazon-ssm-agent.exeを実行しても、マネージドインスタンスとしてSystems Managerのマネージメントコンソールからは見えてきません。

以下ページにある手順でIAMロールを作成して、インスタンスに割り当てて、amazon-ssm-agent.exeを実行したら、マネージドインスタンスとして表示されました。

Systems Manager のアクセス設定 - AWS Systems Manager

Windows EC2インスタンスを起動する際に、最初からこちらのIAMロールを割り当てて起動すると、自動でSSMエージェントが実行されて、マネージドインスタンスとして表示されるようです。
f:id:kenjifunasaki:20180502105453p:plain

注意事項
起動したインスタンスは、アウトバウンドでSystems Managerのエンドポイントと通信できる必要があります。Systems Manager用のVPCエンドポイントを設定するか、インターネットにアウトバウンド通信できるように、起動したインスタンスのサブネットのルートテーブルを設定する必要があります。

AWS Systems Managerでインベントリを実行して、/home/ec2-user以下にある*.txtファイルを確認、さらにカスタムインベントリで独自メタデータも登録・確認してみる。

事前にEC2インスタンスにSSM(Systems Manager)エージェントをインストール済みとします。

まずはAWS Systems Managerのマネージメントコンソールにて、Inventoryを選択して、セットアップインベントリを選択します。
f:id:kenjifunasaki:20180427192524p:plain

インスタンスの手動選択」にて、該当するインスタンスを選択します。スケジュールはCronスケジュールビルダーを選んで、今回は30分ごとの実行とします。
f:id:kenjifunasaki:20180427192914p:plain

同じ画面のパラメータにて、デフォルト設定のままで、ファイルの部分のパスに/home/ec2-userを、パターンに*.txtを、再帰的にチェックを入れて「セットアップインベントリ」を選択します。
f:id:kenjifunasaki:20180427194151p:plain

Managed Instancesを選択して、先ほど指定したインスタンスを選択します。
f:id:kenjifunasaki:20180427194001p:plain

インベントリタブを選択して、インベントリタイプにてAWS:Fileを選択します。
f:id:kenjifunasaki:20180427194357p:plain

最初は何もFile情報が表示されませんが、少し時間がたってから確認すると、以下のようにファイルがあることが確認できます。
f:id:kenjifunasaki:20180427200023p:plain

カスタムインベントリを実行してみる

続いて、こちら にあるCustom Inventoryの方法を用いて、独自のメタデータインスタンスに割り当ててみます。

独自のメタデータインスタンスに割り当てる方法として、AWS CLIを使う方法が紹介されていたので、こちらでやってみます。

AWS CLIでコマンドを実行するのに必要な権限を割り当てた上で以下コマンドを実行します。

https://docs.aws.amazon.com/systems-manager/latest/userguide/sysman-inventory-walk-custom.html

State Managerを選択して、関連づけ(AWS-GatherSoftwareInventory)を選択して「関連付けの編集」を選択します。

aws ssm put-inventory --instance-id "xxxx" --items '[{"CaptureTime": "2018-04-30T10:01:01Z", "TypeName": "Custom:RackInfo", "Content":[{"RackLocation": "Bay B/Row C/Rack D/Shelf E"}], "SchemaVersion": "1.0"}]'

実行後に、そのメタデータが取得できるようになっているかを以下コマンドで確認します。

aws ssm list-inventory-entries --instance-id xxx --type-name "Custom:RackInfo"

結果は以下のように出力され、正しくメタデータが登録されていることがわかりました。

{
    "InstanceId": "i-005991248a5f30bc2",
    "TypeName": "Custom:RackInfo",
    "Entries": [
        {
            "RackLocation": "Bay B/Row C/Rack D/Shelf E"
        }
    ],
    "SchemaVersion": "1.0",[f:id:kenjifunasaki:20180430210852p:plain]
    "CaptureTime": "2018-04-30T10:01:01Z"
}

Management Console上でも以下のようにカスタムインベントリ情報を選択ができ、
f:id:kenjifunasaki:20180430210819p:plain

登録したメタデータも確認ができました。
f:id:kenjifunasaki:20180430210852p:plain

これで、デフォルトのインベントリ以外でも任意のメタデータをマネージドインスタンスごとに登録・取得できますね。

注意事項

一つのマネージドインスタンスに複数のインベントリを関連づけることはできません。すでに別のインベントリが関連付けされていると、別のインベントリの実行が失敗しますので、ご注意ください。
